BQCH3B025 - 25Amp Circuit Breaker

BQCH3B025 - 25Amp Circuit Breaker

Finding the correct replacement breaker starts with matching the original specifications of the equipment already in service. The BQCH3B025 is a 25 amp, 3-pole molded case circuit breaker designed for applications that require a BQCH frame and a bolt-on mounting configuration. Built for use in compatible three-phase electrical systems, this breaker features a 14kA interrupting rating at 480VAC and is commonly found in commercial and industrial power distribution equipment where maintaining proper fit and electrical ratings is important.

The 3-pole design makes the BQCH3B025 suitable for a wide range of three-phase applications, including HVAC equipment, refrigeration systems, motor circuits, control panels, and branch circuit protection. Its HACR rating allows it to be used in heating, air conditioning, and refrigeration installations where that designation is required. Rated for operation in 40°C ambient environments, this breaker is intended for use in facilities that depend on consistent electrical distribution and properly matched replacement components. Whether you're replacing an existing breaker during scheduled maintenance or restoring equipment to its original specifications, the BQCH3B025 provides the form, fit, and function required for compatible installations. Built to last, it is designed for equipment that calls for these exact ratings and configuration requirements.

Key Features and Benefits

• 25 amp current rating
• Three-pole configuration for three-phase electrical systems
• Bolt-on mounting design for secure installation
• BQCH frame type
• Molded case circuit breaker construction
• 14kA interrupting rating at 480VAC
• HACR rated for HVAC and refrigeration applications
• Rated for operation in ambient temperatures up to 40°C
• Helps maintain original equipment specifications in existing installations
• Suitable for commercial, industrial, and facility maintenance applications
• Built to last


Technical Specifications

• Part Number: BQCH3B025

• Frame Type: BQCH

• Circuit Breaker Type: Molded Case Circuit Breaker

• Poles: 3

• Amperage Rating: 25 Amps

• Voltage Rating: 480VAC

• Interrupting Rating: 14kA @ 480VAC

• Mounting Type: Bolt-On

• Ambient Temperature Rating: 40°C

• HACR Rated: Yes

• Dimensions:
  • Width: 3.00 in.
  • Height: 4.49 in.
  • Depth: 2.70 in.
• Dimensions: 3.00"W x 4.49"H x 2.70"D

• Approximate Shipping Weight: 4.0 lbs.


Material Compliance and Certifications

• HACR Rated
• Molded Case Circuit Breaker construction
• Rated for operation in 40°C ambient conditions
• Suitable for use in compatible BQCH frame electrical equipment
• Designed to meet published electrical ratings and application requirements


Where It Works Best

• The BQCH3B025 is commonly used in commercial buildings, manufacturing facilities, warehouses, schools, healthcare facilities, and other locations that utilize three-phase electrical distribution systems. Typical applications include HVAC systems, refrigeration equipment, motor control circuits, branch circuit protection, electrical distribution equipment, and industrial control panels requiring a 25 amp 3-pole bolt-on circuit breaker with a 14kA interrupting rating at 480VAC.

• When maintaining existing electrical infrastructure, matching the original frame type, mounting style, amperage rating, and voltage specifications is essential. The BQCH3B025 is designed for installations that require a compatible replacement breaker meeting those exact requirements.
