BQCH1B060 - 60Amp Circuit Breaker

BQCH1B060 - 60Amp Circuit Breaker

Finding the right replacement breaker often comes down to matching the details. If your equipment calls for a BQCH-frame circuit breaker, the BQCH1B060 provides the 60 amp rating, single-pole configuration, and bolt-on mounting style required for compatible installations. Designed for electrical systems that use a 14kA interrupting rating at 277VAC, this breaker helps maintain the original specifications of the equipment it's installed in.

Whether you're replacing a failed breaker, performing scheduled maintenance, or sourcing a matching component for an existing installation, having the correct frame type and electrical ratings matters. The BQCH1B060 is built to last and continues to be used in commercial, industrial, and institutional facilities that rely on compatible electrical distribution equipment every day.

Key Features and Benefits

• 60 amp current rating
• Single-pole design
• Bolt-on mounting configuration
• BQCH frame type
• Molded case circuit breaker construction
• 14kA interrupting rating at 277VAC
• HACR rated
• Rated for operation in 40°C ambient conditions
• Intended for use in compatible electrical equipment
• Built for long-term service


Technical Specifications

• Part Number: BQCH1B060

• Product Type: Molded Case Circuit Breaker

• Frame Type: BQCH

• Poles: 1

• Amperage Rating: 60 Amps

• Voltage Rating: 277VAC

• Interrupting Rating: 14kA @ 277VAC

• Mounting Type: Bolt-On

• Ambient Temperature Rating: 40°C

• HACR Rated: Yes

• Dimensions:
  • Width: 1.00 in.
  • Height: 4.49 in.
  • Depth: 2.70 in.
• Approximate Shipping Weight: 2.0 lbs.


Material Compliance and Certifications

• HACR Rated
• Molded case circuit breaker construction
• Intended for installation in properly rated compatible equipment
• Manufactured for use in low-voltage electrical distribution systems


Where It Works Best

• The BQCH1B060 is commonly used in office buildings, schools, warehouses, healthcare facilities, retail locations, manufacturing plants, and other facilities utilizing compatible electrical distribution equipment. Typical applications include lighting circuits, HVAC systems, refrigeration equipment, control panels, branch circuits, and general power distribution where a 60 amp, single-pole bolt-on molded case circuit breaker with a 14kA interrupting rating at 277VAC is required.
