BQCH1B030 - 30Amp Circuit Breaker

BQCH1B030 - 30Amp Circuit Breaker

The BQCH1B030 is a 30 amp, single-pole bolt-on molded case circuit breaker designed for your electrical systems that require a BQCH frame and a 14kA interrupting rating at 277VAC. In many cases, replacement work comes down to matching the breaker that's already in the panel. This model is intended for applications where the existing equipment calls for these specific ratings, dimensions, and mounting requirements.

The breaker features a bolt-on connection, making it suitable for compatible panelboards and distribution equipment designed around the BQCH platform. Its HACR rating allows it to be used in heating, air conditioning, and refrigeration applications where required by the original system design. Rated for operation in 40°C environments, the BQCH1B030 is commonly used in lighting panels, HVAC equipment, control systems, and general power distribution applications.

Whether it's part of a facility maintenance project, an equipment repair, or a scheduled breaker replacement, matching the original specifications helps you keep the system configured as intended.

Key Features and Benefits

• 30 amp current rating
• Single-pole configuration
• Bolt-on mounting style
• BQCH frame type
• Molded case circuit breaker construction
• 14kA interrupting rating at 277VAC
• HACR rated
• Rated for operation in 40°C ambient conditions
• Intended for use in compatible electrical equipment
• Built for long-term service


Technical Specifications

• Part Number: BQCH1B030

• Product Type: Molded Case Circuit Breaker

• Frame Type: BQCH

• Poles: 1

• Amperage Rating: 30 Amps

• Mounting Type: Bolt-On

• Interrupting Rating: 14kA @ 277VAC

• Ambient Temperature Rating: 40°C

• HACR Rated: Yes

• Dimensions:
  • Width: 1.00 in.
  • Height: 4.49 in.
  • Depth: 2.70 in.
• Approximate Shipping Weight: 2.0 lbs.


Material Compliance and Certifications

• HACR Rated
• Manufactured for use in low-voltage electrical distribution systems
• Intended for installation in properly rated compatible equipment


Where It Works Best

• The BQCH1B030 is commonly found in commercial buildings, warehouses, schools, healthcare facilities, manufacturing plants, and office properties that utilize compatible electrical distribution equipment.
