BQCH1B025 - 25Amp Circuit Breaker

BQCH1B025 - 25Amp Circuit Breaker

The BQCH1B025 is a 25 amp, 1-pole bolt-on molded case circuit breaker designed for electrical systems that require a compatible BQCH-frame breaker with a 14kA interrupting rating at 277VAC. When you're maintaining existing power distribution equipment, finding the correct replacement is about more than matching amperage alone—it also means matching the original mounting style, frame type, and electrical ratings. This breaker is built to provide the form, fit, and function needed for compatible installations, helping keep existing systems operating as intended.

Featuring a bolt-on design for secure installation, the BQCH1B025 is commonly used in commercial and industrial environments where branch circuit protection is required. It helps protect your electrical circuits from overloads and short circuits while supporting the continued operation of panelboards, distribution equipment, HVAC systems, and refrigeration applications. Because it is HACR rated and suitable for operation in 40°C ambient conditions, it is often specified for facilities that rely on established electrical infrastructure and equipment compatibility.

From office buildings and schools to warehouses, retail facilities, and manufacturing plants, the BQCH1B025 remains a practical choice for electricians, maintenance teams, and facility managers working on repair and replacement projects. Built to last and designed around established electrical specifications, this molded case circuit breaker helps maintain compatibility where matching the original equipment is a priority.

Key Features and Benefits

• 25 amp current rating
• Single-pole configuration
• Bolt-on mounting design for compatible equipment
• BQCH frame type
• Molded case circuit breaker construction
• 14kA interrupting rating at 277VAC
• HACR rated
• Rated for operation in ambient temperatures up to 40°C
• Designed for overload and short-circuit protection
• Built to last in commercial and industrial applications
• Intended for maintenance, repair, and replacement projects requiring matching specifications


Technical Specifications

• Part Number: BQCH1B025

• Product Type: Molded Case Circuit Breaker

• Frame Type: BQCH

• Poles: 1

• Amperage Rating: 25 Amps

• Mounting Type: Bolt-On

• Interrupting Rating: 14kA @ 277VAC

• Ambient Temperature Rating: 40°C

• HACR Rated: Yes

• Dimensions:
  • Width: 1.00 in.
  • Height: 4.49 in.
  • Depth: 2.70 in.
• Approximate Shipping Weight: 2.0 lbs.


Material Compliance and Certifications

• HACR Rated
• Molded Case Circuit Breaker
• Designed for use in properly rated compatible electrical equipment
• Suitable for installation in commercial and industrial electrical distribution systems when applied within specified ratings


Where It Works Best

• The BQCH1B025 is commonly found in commercial buildings, educational facilities, healthcare environments, warehouses, manufacturing plants, and retail locations utilizing compatible electrical distribution equipment. Typical applications include branch circuit protection, lighting circuits, HVAC systems, refrigeration equipment, control panels, and general power distribution. It is particularly well suited for projects where maintaining the original electrical specifications and equipment compatibility is a key requirement.
