The BQCH1B015 is a 15 amp, single-pole molded case circuit breaker with a bolt-on mounting design and a 14kA interrupting rating at 277VAC. It is used in your electrical distribution systems that require a breaker with these specific ratings and a BQCH frame configuration. For many replacement projects, the most important consideration is matching the existing breaker's amperage, frame type, mounting style, and interrupting capacity. The BQCH1B015 is intended for those applications.

This breaker is regularly used in lighting panels, control equipment, HVAC systems, and general electrical distribution equipment. Its HACR rating allows it to be used in heating, air conditioning, and refrigeration applications where a properly rated breaker is required. Rated for operation in 40°C ambient conditions, it is suitable for a variety of commercial and industrial installations.

Built to last, the BQCH1B015 remains a common choice when you're maintaining existing equipment and keeping electrical systems configured as originally designed.

Key Features and Benefits

• 15 amp current rating
• Single-pole design
• Bolt-on mounting configuration
• BQCH frame type
• Molded case circuit breaker construction
• 14kA interrupting rating at 277VAC
• HACR rated
• Rated for 40°C ambient operation
• Intended for use in compatible electrical equipment
• Built for long-term service


Technical Specifications

• Part Number: BQCH1B015

• Product Type: Molded Case Circuit Breaker

• Frame Type: BQCH

• Mounting Type: Bolt-On

• Number of Poles: 1

• Amperage Rating: 15 Amps

• Interrupting Rating: 14kA @ 277VAC

• Ambient Temperature Rating: 40°C

• HACR Rated: Yes

• Width: 1.00 in.

• Height: 4.49 in.

• Depth: 2.70 in.

• Dimensions:
  • Width: 1.00"
  • Height: 4.49"
  • Depth: 2.70"
• Approximate Shipping Weight: 2.0 lbs.


Material Compliance and Certifications

• HACR Rated
• Manufactured for use in low-voltage electrical distribution systems
• Intended for installation in properly rated compatible equipment


Where It Works Best

• The BQCH1B015 is used in commercial buildings, schools, warehouses, office facilities, manufacturing plants, and other locations utilizing compatible electrical distribution equipment. Typical applications include lighting circuits, HVAC equipment, control panels, branch circuits, and power distribution systems requiring a 15 amp, single-pole bolt-on circuit breaker with a 14kA interrupting rating at 277VAC.
