BQ3B080H - 80Amp Circuit Breaker

BQ3B080H - 80Amp Circuit Breaker

The Siemens BQ3B080H is an 80-amp, 3-pole molded case circuit breaker used in 240V three-phase electrical distribution systems. It features a common-trip design that opens all three poles simultaneously when an overload or short circuit occurs. The breaker is part of Siemens' Type BQH product line and is commonly installed in panelboards, load centers, and distribution equipment that require an 80-amp, 3-pole breaker with a higher interrupting rating.

This model carries a 22 kA interrupting capacity and includes load-side lugs from the factory. The bolt-on connection provides a secure installation in compatible Siemens equipment. Its compact footprint makes it suitable for branch circuits, feeder circuits, HVAC equipment, and other commercial or light industrial electrical applications where space inside the panel may be limited.

Whether you're using it as a replacement breaker or installed as part of a new electrical distribution system, the BQ3B080H provides the ratings and configuration required for many three-phase applications. Like other Siemens molded case breakers, it is built for long-term service in everyday operating conditions.

Key Features and Benefits

• 80 amp continuous current rating
• Three-pole common-trip operation
• Rated for 240 VAC systems
• 22 kA interrupting rating (AIR)
• Bolt-on mounting configuration
• Load-side lugs included
• Molded case construction
• Designed for branch and feeder circuit protection
• Suitable for commercial and light industrial applications
• UL 489 Listed


Technical Specifications

• Catalog Number: BQ3B080H

• Manufacturer: Siemens

• Product Series: BQH

• Product Type: Molded Case Circuit Breaker

• Ampere Rating: 80 Amps

• Number of Poles: 3

• Voltage Rating: 240 VAC

• Interrupting Rating: 22 kA AIR

• Trip Configuration: Common Trip

• Connection Type: Bolt-On

• Depth: 3 in.

• Width: 3 in.

• Height: 4 in.

• Net Weight: 1.146 lb

• Country of Origin: Mexico


Material Compliance and Certifications

• UL 489 Listed
• Manufactured for low-voltage electrical distribution applications
• Built to Siemens product standards


Where It Works Best

• The Siemens BQ3B080H is commonly found in commercial buildings, schools, retail facilities, warehouses, apartment complexes, and light industrial environments. Typical applications include panelboards, feeder circuits, branch circuits, HVAC equipment, motor loads, and general power distribution systems requiring an 80-amp, 3-pole, 240-volt circuit breaker with a 22 kA interrupting rating.
