BQ3B060H - 60Amp Circuit Breaker

BQ3B060H - 60Amp Circuit Breaker

The Siemens BQ3B060H is a 60-amp, 3-pole molded case circuit breaker for 240V electrical systems. Its common-trip design opens all three poles at once during an overload or short circuit, providing protection for wiring and connected equipment. Part of Siemens’ Type BQH series, this breaker includes a bolt-on connection and factory-installed load-side lugs, making it suitable for installation in compatible panelboards and distribution equipment.

With a 22 kA interrupting rating and UL 489 listing, the BQ3B060H is used in commercial buildings, schools, offices, retail spaces, apartment complexes, and light industrial facilities.

Key Features

• 60 amp continuous current rating
• 3-pole common-trip design
• Rated for 240 VAC systems
• 22 kA interrupting rating (AIR)
• Bolt-on mounting
• Factory-installed load-side lugs
• Molded case construction


Technical Specifications

• Catalog Number: BQ3B060H

• Manufacturer: Siemens

• Product Series: BQH

• Ampere Rating: 60 Amps

• Number of Poles: 3

• Trip Type: Common Trip

• Voltage Rating: 240 VAC

• Interrupting Rating: 22 kA AIR

• Electrical Connection: Bolt-On

• Dimensions: 4 in. D × 3 in. W × 3 in. H

• Net Weight: 1.014 lb

• Country of Origin: Mexico


Material Compliance and Certifications

• UL 489 listed


Where It Works Best

• Installed in panelboards, load centers, branch circuits, feeders, and HVAC systems. Typical locations include commercial offices, schools, retail spaces, apartment complexes, warehouses, and light industrial facilities needing a 60-amp, 3-pole breaker with 22 kA interrupting capacity.
