BQ2B03000S01 - 30Amp Circuit Breaker

BQ2B03000S01 - 30Amp Circuit Breaker

The Siemens BQ2B03000S01 is a 2-pole, 30-amp thermal magnetic circuit breaker designed for your Type BQ electrical distribution equipment. In addition to standard overload and short-circuit protection, this breaker includes a factory-installed 120V shunt trip, allowing the breaker to be opened remotely when connected to a compatible control circuit. This feature is commonly used in emergency shutdown systems, safety interlocks, access control systems, and other applications where remote breaker operation is required.

Rated for 120/240 VAC with a 10 kAIC interrupting capacity, the BQ2B03000S01 is suitable for a variety of branch circuit applications. The common-trip mechanism disconnects both poles simultaneously, while the bolt-on connection and included load-side lugs support installation in compatible Siemens panels and loadcenters.

Key Features and Benefits

• 2-Pole Thermal Magnetic Circuit Breaker: Provides protection against overload and short-circuit conditions.
• 30A Continuous Current Rating: Suitable for branch circuits requiring 30-amp protection.
• Factory-Installed 120V Shunt Trip: Allows remote breaker operation when connected to a compatible control circuit.
• Common-Trip Operation: Disconnects both poles simultaneously during fault conditions.
• Rated for 120/240 VAC Systems: Compatible with standard electrical distribution applications.
• 10 kAIC Interrupting Capacity: Provides reliable fault interruption capability.
• Bolt-On Connection Design: Enables secure installation.
• Load-Side Lugs Included: Ready for wiring connection during installation.
• Type BQ Molded Case Construction: Designed for installation in compatible Siemens panels and loadcenters.
• UL 489 Listed: Certified for branch circuit protection applications.


Technical Specifications

• Manufacturer: Siemens

• Catalog Number: BQ2B03000S01

• MPN: BQ2B03000S01

• UPC: 783643237735

• Product Type: Thermal Magnetic Circuit Breaker

• Circuit Breaker Type: BQ

• Number of Poles: 2

• Current Rating: 30 Amps

• Voltage Rating: 120/240 VAC

• Interrupting Capacity: 10 kAIC

• Shunt Trip Voltage: 120 VAC

• Trip Configuration: Common Trip

• Electrical Connection: Bolt-On

• Load-Side Lugs: Included

• Application: Electrical Distribution

• Dimensions:
  • Depth: 6 in.
  • Width: 4 in.
  • Height: 3 in.
• Net Weight: 0.55 kg

• Country of Origin: Mexico


Material Compliance and Certifications

• UL 489 Listed: The Siemens BQ2B03000S01 is UL 489 Listed for branch circuit protection and is manufactured for use in low-voltage electrical distribution systems.


Where It Works Best

• The BQ2B03000S01 is commonly installed in commercial buildings, industrial facilities, schools, healthcare environments, and other locations where remote breaker operation is required.
