The Eaton BQ240250 Type BQ Quadplex Circuit Breaker packs a 40-amp two-pole breaker and a 50-amp two-pole breaker into a single assembly for Eaton Type BR loadcenters. Its design allows two 240-volt circuits to fit in a single breaker space, making it useful for your panel upgrades, equipment additions, and remodeling projects where multiple circuit sizes are needed.

This breaker is used to supply HVAC systems, heat pumps, water heaters, compressors, pumps, welders, and other 240-volt equipment. The combination of 40A and 50A circuits lets a single assembly handle multiple loads without taking up extra space.

It installs with a plug-on connection, and the integrated rejection tab ensures proper placement in compatible panels. With thermal magnetic trip protection, a 10 kAIC interrupting rating, UL 489 certification, HACR classification, and compatibility with copper and aluminum conductors, the BQ240250 is reliable for your residential and light commercial electrical systems.

Key Features and Benefits

• Quadplex Configuration: One 40A and one 50A two-pole breaker in a single assembly, fitting two 240-volt circuits into a single breaker space.
• Thermal Magnetic Protection: Provides protection against overloads and short circuits using a thermal magnetic trip mechanism.
• Plug-On Installation: Designed for Eaton Type BR loadcenters with a plug-on mounting connection.
• Rejection Tab Feature: Helps ensure proper placement in compatible panels.
• Rated for 120/240 VAC: Suitable for residential and light commercial electrical systems.
• 10 kAIC Interrupting Capacity: Provides dependable fault interruption capability.
• Compatible Conductors: Works with both copper and aluminum conductors.
• HACR Listed: Approved for heating, air conditioning, and refrigeration applications.
• UL 489 Listed: Certified for branch circuit protection applications.


Technical Specifications

• Manufacturer: Eaton

• Catalog Number: BQ240250

• UPC: 786676371209

• Product Type: Thermal Magnetic Circuit Breaker

• Circuit Breaker Type: BQ Quadplex

• Type: Type BQ 1-Inch CTL Plug-On Circuit Breaker

• Amperage Rating: (1) Two-Pole 40A, (1) Two-Pole 50A

• Voltage Rating: 120/240 VAC

• Number of Poles: Four-Pole Configuration

• Trip Type: T194

• Interrupt Rating: 10 kAIC

• Mounting Method: Plug-On

• Compatible Loadcenters: Eaton Type BR

• Wire Size: #14–4 AWG Copper/Aluminum

• Dimensions:
  • Depth: 1.4 in
  • Height: 3.1 in
  • Width: 3.2 in
• Product Weight: 2.5 lb

• Special Feature: Rejection Tab


Material Compliance and Certifications

• UL 489 Listed: Certified for branch circuit protection applications.
• Federal Specifications Classification W-C375: Complies with Federal Specifications Classification W-C375.
• HACR Listed: Approved for heating, air conditioning, and refrigeration applications.


Where It Works Best

• The BQ240250 is installed in residential service panels, multifamily housing, workshops, offices, retail locations, and light commercial facilities where two 240-volt circuits with 40A and 50A are required. Applications include HVAC systems, heat pumps, water heaters, compressors, pumps, welders, and other branch circuits needing two-pole protection.
