BQ230250 - Quadplex 30/50 Circuit Breaker

BQ230250 - Quadplex 30/50 Circuit Breaker

Ensure the safety and efficiency of your electrical systems with the Eaton BQ230250 Quadplex Circuit Breaker. This premium-quality breaker, designed for both residential and light commercial setups, is engineered to provide superior protection by combining two independent poles with a common trip feature. Each unit features one two-pole breaker rated at 30 A and another rated at 50 A, making it versatile for various applications.

Key Features and Benefits:

• Dual Protection: Offers two levels of amperage, essential for systems requiring varied load protection.
• Rejection Tab Feature: Enhances safety by preventing improper breaker installation, ensuring your setup is secure and reliable.
• Compact Design: A slim 1-inch frame that easily fits into Type BR load centers, optimizing your panel space without sacrificing performance.
• High Interrupt Rating (10 kAIC): Provides excellent protection against high current surges, minimizing the risk of damage to your electrical system and connected devices.

Technical Specifications:

• Amperage Rating: 30A and 50A
• Voltage Rating: 120/240 V for broad compatibility with residential and commercial power systems.
• Wire Size: Accepts #14-4 AWG Cu/Al, providing flexibility in wire choice and enhancing installation convenience.
• Mounting Method: Plug-on design for easy and secure attachment to compatible load centers.

Material Compliance and Certifications:

• UL Listed (UL 489): Meets rigorous safety standards, ensuring the breaker's reliability and quality.
• Federal Specifications Classification W-C375: Complies with federal safety and performance criteria, assuring you of a top-tier product.

Suitability:

• Ideal for use with Type BR load centers, this circuit breaker is perfect for homes, small offices, and light commercial buildings that require dependable and efficient circuit protection. Whether upgrading your existing system or installing new electrical infrastructure, the Eaton BQ230250 provides the protection your system needs without compromise.
