BGA36025 - 25Amp Circuit Breaker

BGA36025 - 25Amp Circuit Breaker

The Schneider Electric PowerPacT BGA36025 Circuit Breaker provides industry-leading thermal magnetic protection, making it an essential choice for safeguarding electrical systems in residential, commercial, and industrial environments. This compact, 3-pole circuit breaker is rated at 25A and offers a breaking capacity of 18kA at 600Y/347 VAC, ensuring superior performance in critical applications. Designed with efficiency and sustainability in mind, the BGA36025 features dual-break rotating contacts to minimize peak current during faults, enhancing operational safety and longevity.

Key Features and Benefits

• Thermal Magnetic Protection: Offers precise and reliable protection against overloads and short circuits to ensure system stability.
• Durable Construction: Engineered for 20,000 mechanical cycles and 10,000 electrical cycles, delivering long-lasting performance even under demanding conditions.
• Dual-Break Rotating Contacts: Reduces peak current during faults, protecting connected systems and components.
• Eco-Friendly Design: Made with recycled materials, PVC-free construction, and shipped in sustainable packaging to minimize environmental impact.
• Enhanced Usability: Equipped with an integral push-to-trip button and a semi-transparent front cover for quick identification and manual control.


Technical Specifications

• Rated Current: 25A

• Poles: 3-pole configuration

• Voltage Rating: 600Y/347 VAC with 18kA breaking capacity

• Compliance: Certified to UL 489, CSA, NOM, and IEC standards, ensuring global compatibility.

• Dimensions: Compact design with a height of 5.4 inches, width of 3.2 inches, and depth of 3.5 inches for space-saving installation.

• Environmental Performance: Operates reliably within a temperature range of -25å¡C to 70å¡C (-13å¡F to 158å¡F) and at altitudes up to 2000m without derating.


Material Compliance and Certifications

• RoHS & REACH Compliance: Free from hazardous materials to promote sustainability.
• Halogen-Free Design: Minimizes environmental hazards and supports clean energy goals.
• California Proposition 65: Clearly labeled for transparency regarding potential risks.


Suitability

• This HACR-rated circuit breaker is perfect for a wide array of applications, including HVAC systems, panelboards, and distribution systems. Its I-Line design simplifies installation, making it an excellent choice for contractors and system integrators looking for reliable, high-performance solutions.
