BF230A - 30Amp Circuit Breaker

BF230A - 30Amp Circuit Breaker

The Siemens BF230A is a 30 amp, 2-pole GFCI circuit breaker rated for your 120/240VAC applications. It provides thermal-magnetic overcurrent protection and 5 mA ground fault protection in one device. The BF230A is designed for use in compatible Siemens panelboards and is commonly used when replacing an existing breaker with the same ratings and configuration.

This breaker features a 10kAIC interrupting rating, a bolt-on connection, and molded case construction.

Key Features and Benefits

• 30A current rating
• 2-pole design
• 120/240VAC rating
• Class A GFCI protection
• 5 mA ground fault trip level
• Thermal-magnetic trip mechanism
• 10kAIC interrupting rating
• Bolt-on mounting
• Molded case construction
• Compatible with designated Siemens panelboards


Technical Specifications

• Manufacturer: Siemens

• Catalog Number: BF230A

• Series: BLF/GFCL

• Product Type: GFCI Circuit Breaker

• Amperage Rating: 30A

• Number of Poles: 2

• Voltage Rating: 120/240VAC

• Interrupting Rating: 10kAIC

• Ground Fault Trip Level: 5 mA

• Trip Type: Thermal-Magnetic

• Connection Type: Bolt-On

• Dimensions:
  • Length: 7.874 in.
  • Width: 1.969 in.
  • Height: 2.756 in.
• Weight: 0.992 lb

• UPC: 887621215415

• Country of Origin: Philippines


Material Compliance and Certifications

• UL 943 Listed
• Suitable for Class A GFCI applications
• Manufactured for electrical distribution equipment
• Meets applicable electrical installation requirements


Where It Works Best

• The BF230A is used in commercial buildings, schools, healthcare facilities, workshops, utility rooms, maintenance areas, and industrial facilities where 120/240VAC GFCI protection is required. It is commonly installed in maintenance and replacement projects that require the same amp rating, pole configuration, voltage rating, and interrupting capacity as the original breaker.
