BDA36070 - 70Amp Circuit Breaker

BDA36070 - 70Amp Circuit Breaker

The Schneider Electric BDA36070 circuit breaker, part of the PowerPacT B-Frame series, offers reliable and efficient circuit protection in demanding electrical distribution systems. Designed for a rated current of 70A and 3-pole configuration, this compact breaker operates seamlessly at 600Y/347VAC with a robust breaking capacity of 14kA. Its thermal-magnetic technology ensures effective overcurrent protection while reducing peak currents during short-circuit conditions through its innovative dual-break rotating contacts.

Key Features and Benefits

• Advanced Protection: Thermal-magnetic trip technology with a 14kA breaking capacity ensures reliable operation.
• Compact and Efficient: Space-saving design with I-Line mount simplifies installation.
• User-Friendly Design: Semi-transparent cover for easy inspections and QR code-enabled documentation access.
• Customizable: Compatible with an extensive range of accessories for tailored configurations.

Technical Specifications

• Rated Current: 70A
• Poles: 3
• Voltage: 600Y/347VAC
• Breaking Capacity: 14kA
• Dimensions: 5.4 in (H) x 3.2 in (W) x 3.5 in (D)
• Weight: 2.899 lb

Material Compliance and Certifications

• Certifications: CE marked, RoHS compliant, and Green Premium‰ã¢ labeled.
• Environmental Compliance: Mercury-free, halogen-free, and PVC-free design.
• Durability: Rated for 20,000 mechanical cycles and 10,000 electrical cycles for long-lasting reliability.


Suitability

• The BDA36070 circuit breaker is ideal for industrial and commercial systems requiring consistent performance and robust protection. With its innovative safety features, versatile compatibility, and environmentally responsible design, it provides an optimal solution for modern electrical distribution networks.
