BAB3070H - 70Amp Circuit Breaker

BAB3070H - 70Amp Circuit Breaker

Protect your commercial or industrial 240V system with the Eaton BAB3070H. This 70-amp, three-pole thermal magnetic circuit breaker keeps your wiring and equipment safe from overloads and short circuits, making it ideal for demanding electrical setups.

With Eaton’s Quicklag thermal magnetic technology, the BAB3070H ensures reliable trip protection while its bolt-on design makes installation secure and straightforward. Its HACR rating means it’s ready for HVAC and refrigeration systems, and it’s specifically designed for three-phase, four-wire applications.

This breaker fits perfectly in commercial panels, industrial control systems, motor applications, and electrical distribution equipment, giving you peace of mind that your system is safeguarded.

Key Features and Benefits

• 70 Amp thermal magnetic protection: Designed to provide reliable circuit protection for commercial and industrial systems.
• Three-pole design for three-phase systems: Suitable for three-phase electrical applications.
• 240V voltage rating: Designed for use in commercial and industrial 240V electrical systems.
• 10 kAIC interrupt rating: Provides dependable protection during fault conditions.
• Bolt-on mounting for secure installation: Ensures safe and straightforward installation in compatible panels.
• Eaton Quicklag industrial circuit breaker: Utilizes Eaton’s Quicklag thermal magnetic technology for reliable performance.
• HACR rated for HVAC/refrigeration: Suitable for HVAC and refrigeration equipment applications.
• Non-interchangeable trip: Maintains consistent protection for the specified circuit.

• Protects against overloads and short circuits: Provides dependable electrical protection for demanding applications.

Technical Specifications

• Manufacturer: Eaton

• Catalog Number: BAB3070H

• Breaker Type: BAB

• Number of Poles: 3

• Number of Wires: 4

• Voltage Rating: 240V

• Amperage Rating: 70A

• Interrupt Rating: 10 kAIC

• Mounting Method: Bolt-on

• Dimensions:
  • Depth: 3.9 in.
  • Height: 4.9 in.
  • Width: 3.2 in.
• Weight: 1.05 lb

• Warranty: 1 Year


Material Compliance and Certifications

• UL Listed: Manufactured to meet applicable UL safety standards for electrical protection devices.
• CSA Certified: Certified for compliance with recognized Canadian safety standards.
• HACR Rated: Suitable for HVAC and refrigeration equipment applications.


Where It Works Best

• The Eaton BAB3070H works well in commercial electrical panels, industrial distribution systems, HVAC and refrigeration equipment, motor control applications, and three-phase electrical setups where dependable circuit protection is required.
