BAB3060H - 60Amp Circuit Breaker

BAB3060H - 60Amp Circuit Breaker

The Eaton BAB3060H is a 60 amp, 3-pole thermal magnetic circuit breaker made for commercial and industrial electrical systems that need reliable circuit protection. It helps protect your circuits and connected equipment from overloads and short circuits while supporting steady everyday operation. The bolt-on mounting design provides a secure fit in compatible distribution panels, making it a practical choice for systems where dependable electrical performance matters.

Part of Eaton’s Quicklag BAB series, the BAB3060H is commonly used in HVAC equipment, motor controls, pumps, compressors, and other three-phase applications. Its thermal-magnetic trip mechanism responds quickly during fault conditions while allowing normal electrical loads to operate as expected. Designed for use in 240V three-phase, four-wire systems, this breaker works well in a range of commercial and industrial power distribution applications.

With a 10 kAIC interrupt capacity and HACR certification, the BAB3060H is built for environments where reliable electrical protection is important.

Key Features and Benefits

• 60 amp thermal magnetic circuit breaker: Designed for dependable circuit protection in commercial and industrial electrical systems.
• Three-pole design: Suitable for three-phase systems used in a variety of electrical distribution applications.
• Bolt-on mounting: Provides a secure installation in compatible distribution panels.
• Protection against overloads and short circuits: Helps protect circuits and connected equipment during fault conditions.
• Designed for 240V three-phase, four-wire systems: Works well in a range of commercial and industrial power distribution applications.
• HACR rated: Suitable for HVAC and refrigeration equipment.
• Suitable for commercial and industrial applications: Built for reliable everyday operation in demanding electrical systems.
• Reliable everyday performance: Supports steady operation in commercial and industrial electrical environments.


Technical Specifications

• Manufacturer: Eaton

• Catalog Number: BAB3060H

• Series: BAB Quicklag

• Amperage Rating: 60A

• Voltage Rating: 240V

• Number of Poles: 3-Pole

• Number of Wires: 4

• Interrupt Rating: 10 kAIC

• Trip Type: Non-Interchangeable

• Mounting Method: Bolt-On

• Circuit Breaker Type: Thermal Magnetic

• Dimensions:
  • Width: 3.8 in.
  • Length: 4.7 in.
  • Depth: 3.2 in.
• Weight: 0.95 lb

• Warranty: 1 Year


Material Compliance and Certifications

• UL Listed: Manufactured to meet applicable UL safety standards for electrical protection devices.
• CSA Certified: Certified for compliance with recognized Canadian safety standards.
• HACR Rated: Suitable for HVAC and refrigeration equipment.


Where It Works Best

• The Eaton BAB3060H works well in commercial electrical systems, industrial facilities, HVAC and refrigeration equipment, motor control applications, pumps and compressors, distribution panels, three-phase power systems, and 240V three-phase, four-wire applications where dependable circuit protection is required.
