BAB3050HT - 50Amp Circuit Breaker

BAB3050HT - 50Amp Circuit Breaker

The Eaton BAB3050HT is a 50 amp, 3-pole thermal magnetic circuit breaker designed for commercial and industrial electrical systems. It helps protect your circuits and connected equipment from overloads and short circuits while supporting reliable everyday operation. The bolt-on mounting design provides a secure connection in compatible panelboards, making it a solid fit for electrical distribution systems where dependable protection matters.

Part of Eaton’s Quicklag BAB series, the BAB3050HT is commonly used in HVAC equipment, motor controls, pumps, compressors, and other three-phase applications. Its thermal-magnetic trip mechanism responds quickly during fault conditions while allowing normal electrical loads to operate without unnecessary interruptions. Ring or spade lug terminal compatibility also provides added flexibility during installation and maintenance.

With a 240V rating and 10 kAIC interrupt capacity, this breaker is built for commercial and industrial environments that require steady electrical performance and reliable circuit protection.

Key Features and Benefits

• 50 amp thermal magnetic circuit breaker: Designed for dependable circuit protection in commercial and industrial electrical systems.
• Three-pole design: Suitable for three-phase systems used in a variety of electrical distribution applications.
• Bolt-on mounting: Provides a secure installation in compatible panelboards.
• Protection against overloads and short circuits: Helps protect circuits and connected equipment during fault conditions.
• Compatible with ring or spade lug terminals: Provides added flexibility during installation and maintenance.
• HACR rated: Suitable for HVAC and refrigeration systems.
• Compact design: Helps when working with panelboard applications where installation space may be limited.
• Suitable for commercial and industrial use: Built for reliable everyday operation in demanding electrical systems.


Technical Specifications

• Manufacturer: Eaton

• Catalog Number: BAB3050HT

• Series: BAB Quicklag

• Amperage Rating: 50A

• Voltage Rating: 240V

• Number of Poles: 3-Pole

• Interrupt Rating: 10 kAIC

• Trip Type: Non-Interchangeable

• Mounting Method: Bolt-On

• Terminal Type: Ring or Spade Lug

• Circuit Breaker Type: Thermal Magnetic

• Dimensions:
  • Width: 3.7 in.
  • Length: 5 in.
  • Depth: 3 in.
• Weight: 0.9 lb

• Warranty: 1 Year


Material Compliance and Certifications

• UL Listed: Manufactured to meet applicable UL safety standards for electrical protection devices.
• CSA Certified: Certified for compliance with recognized Canadian safety standards.
• HACR Rated: Suitable for HVAC and refrigeration systems.


Where It Works Best

• The Eaton BAB3050HT works well in commercial electrical systems, industrial facilities, HVAC and refrigeration equipment, motor control applications, pumps and compressors, three-phase power systems, and electrical distribution panels where dependable circuit protection is required.
