BAB2100 - 100Amp Circuit Breaker

BAB2100 - 100Amp Circuit Breaker

The Eaton BAB2100 circuit breaker provides reliable protection for commercial and industrial electrical systems using 120/240V power. Rated at 100 amps, this two-pole breaker helps protect your wiring and connected equipment from overloads and short circuits.

Part of Eaton’s Quicklag industrial breaker series, the BAB2100 features thermal magnetic trip protection and a bolt-on mounting design for a secure fit in compatible panelboards. Its HACR rating also makes it suitable for HVAC and refrigeration systems where dependable circuit protection is important.

The BAB2100 is commonly used in commercial electrical panels, branch circuit protection, industrial controls, and electrical distribution systems.

Key Features and Benefits

• 100 amp thermal magnetic circuit breaker: Provides reliable protection for commercial and industrial electrical systems.
• Two-pole configuration: Designed for 120/240V applications.
• 120/240V voltage rating: Suitable for commercial and industrial electrical systems.
• 10 kAIC interrupt rating: Supports dependable interruption during fault conditions.
• Eaton Quicklag industrial breaker: Built for commercial and industrial electrical environments.
• Bolt-on mounting: Provides a secure fit in compatible panelboards.
• Thermal magnetic trip protection: Helps protect against overloads and short circuits.
• HACR rated: Suitable for HVAC and refrigeration systems.
• Helps protect against overloads and short circuits: Supports dependable circuit protection.


Technical Specifications

• Manufacturer: Eaton

• Catalog Number: BAB2100

• Product Type: Thermal Magnetic Circuit Breaker

• Breaker Type: BAB

• Number of Poles: 2

• Amperage Rating: 100 Amps

• Voltage Rating: 120/240V

• Interrupt Rating: 10 kAIC

• Trip Type: Non-Interchangeable

• Mounting Method: Bolt-On

• Dimensions:
  • Depth: 3.5 in.
  • Height: 3 in.
  • Width: 1.875 in.
• Product Weight: 0.65 lb

• Warranty: 1 Year


Material Compliance and Certifications

• UL Listed

• CSA Certified

• HACR Rated


Where It Works Best

• Commercial electrical panels
• HVAC and refrigeration systems
• Industrial control panels
• Branch circuit protection
• Electrical distribution systems
• Retrofit and maintenance applications
