BAB2030 - 30Amp Circuit Breaker

BAB2030 - 30Amp Circuit Breaker

The Eaton BAB2030 circuit breaker provides dependable protection for commercial and industrial electrical systems using 240V power. Rated at 30 amps, this two-pole breaker helps protect your wiring and connected equipment from overloads and short circuits. Part of Eaton’s BAB Quicklag series, the BAB2030 features thermal magnetic trip protection in a compact design that fits compatible panelboards and electrical distribution systems. Its switching neutral capability supports multi-wire branch circuit applications, while ring or spade lug terminals allow for flexible wiring connections. The HACR rating also makes it suitable for HVAC and refrigeration systems. The BAB2030 is commonly used in commercial electrical panels, industrial controls, branch circuit protection, and electrical distribution systems.

Key Features and Benefits

• 30 amp thermal magnetic circuit breaker: Provides dependable protection for commercial and industrial electrical systems.
• Two-pole configuration: Designed for 240V applications.
• 10 kAIC interrupt rating: Supports reliable interruption during fault conditions.
• Eaton BAB Quicklag breaker: Built for commercial and industrial electrical applications.
• Switching neutral capability: Supports multi-wire branch circuit applications.
• Ring or spade lug terminals: Allow for flexible wiring connections.
• Thermal magnetic trip protection: Helps respond to overloads and short circuits.
• HACR rated: Suitable for HVAC and refrigeration systems.
• Helps protect against overloads and short circuits: Supports reliable electrical system protection.


Technical Specifications

• Manufacturer: Eaton

• Catalog Number: BAB2030

• Product Type: Thermal Magnetic Circuit Breaker

• Breaker Type: BAB

• Number of Poles: 2

• Amperage Rating: 30 Amps

• Voltage Rating: 240V

• Interrupt Rating: 10 kAIC

• Trip Type: Non-Interchangeable

• Terminal Type: Ring or Spade Lug

• Dimensions:
  • Depth: 3.9 in.
  • Height: 4.8 in.
  • Width: 2.2 in.
• Product Weight: 0.55 lb

• Warranty: 1 Year


Material Compliance and Certifications

• UL Listed

• CSA Certified

• HACR Rated


Where It Works Best

• Commercial electrical panels
• HVAC and refrigeration systems
• Multi-wire branch circuits
• Industrial control panels
• Electrical distribution systems
• Retrofit and maintenance applications
