BAB1070 - 70 Amp Circuit Breaker

BAB1070 - 70 Amp Circuit Breaker

The Eaton BAB1070 circuit breaker provides reliable protection for commercial and industrial electrical systems operating on 120/240V power. Rated at 70 amps, this single-pole breaker helps protect your wiring and connected equipment from overloads and short circuits.

This BAB Quicklag breaker features thermal magnetic trip protection and a bolt-on mounting design for a secure connection in compatible panelboards. Its HACR rating also makes it suitable for HVAC and refrigeration applications where dependable circuit protection is important.

The BAB1070 is commonly used in commercial electrical panels, branch circuit protection, industrial controls, and electrical distribution systems.

Key Features and Benefits

• 70 amp thermal magnetic circuit breaker: Provides dependable circuit protection for commercial and industrial electrical systems.
• Single-pole configuration: Designed for single-pole electrical applications.
• 120/240V voltage rating: Suitable for low-voltage electrical distribution systems.
• 10 kAIC interrupt rating: Helps protect against overloads and short circuits.
• Eaton BAB Quicklag design: Part of Eaton’s trusted BAB Quicklag breaker series.
• Bolt-on mounting: Provides a secure connection in compatible panelboards.
• Thermal magnetic trip protection: Responds to overload conditions and fault currents.
• HACR rated: Suitable for HVAC and refrigeration applications.


Technical Specifications

• Manufacturer: Eaton

• Catalog Number: BAB1070

• Product Type: Thermal Magnetic Circuit Breaker

• Breaker Type: BAB

• Number of Poles: 1

• Amperage Rating: 70 Amps

• Voltage Rating: 120/240V

• Interrupt Rating: 10 kAIC

• Trip Type: Non-Interchangeable

• Mounting Method: Bolt-On

• Dimensions:
  • Depth: 3.7 in.
  • Height: 4.6 in.
  • Width: 1.2 in.
• Product Weight: 0.3 lb

• Warranty: 1 Year


Material Compliance and Certifications

• UL Listed: Manufactured to meet UL listing requirements for electrical protection devices.
• CSA Certified: Certified to applicable CSA standards.
• HACR Rated: Suitable for HVAC and refrigeration applications.


Where It Works Best

• Commercial electrical panels
• HVAC and refrigeration systems
• Branch circuit protection
• Industrial control panels
• Electrical distribution systems
• Retrofit and maintenance applications
