BAB1050 - 50 Amp Circuit Breaker

BAB1050 - 50 Amp Circuit Breaker

The Eaton BAB1050 circuit breaker is designed for commercial and industrial electrical systems that need dependable circuit protection. Rated at 50 amps for 120/240V applications, this single-pole breaker helps protect your wiring and connected equipment from overloads and short circuits.

Part of Eaton’s BAB Quicklag series, the BAB1050 features thermal magnetic trip protection and a bolt-on mounting design for a secure fit in compatible panelboards. It is also HACR rated, making it suitable for HVAC and refrigeration systems, and supports high intensity discharge applications commonly found in commercial lighting setups.

The BAB1050 is commonly used in commercial electrical panels, industrial controls, branch circuit protection, and electrical distribution systems.

Key Features and Benefits

• 50 amp thermal magnetic circuit breaker: Designed for dependable circuit protection in commercial and industrial electrical systems.
• Single-pole configuration: Suitable for standard single-pole electrical applications.
• 120/240V voltage rating: Built for low-voltage electrical distribution systems.
• 10 kAIC interrupt rating: Helps protect against overloads and short circuits.
• Eaton BAB Quicklag breaker: Part of Eaton’s trusted BAB Quicklag series.
• Bolt-on mounting: Provides a secure fit in compatible panelboards.
• Thermal magnetic trip protection: Responds to overload conditions and fault currents.
• HACR rated: Suitable for HVAC and refrigeration applications.
• Suitable for high intensity discharge applications: Commonly used in commercial lighting systems.
• Helps protect against overloads and short circuits: Supports dependable circuit protection in electrical distribution systems.


Technical Specifications

• Manufacturer: Eaton

• Catalog Number: BAB1050

• Product Type: Thermal Magnetic Circuit Breaker

• Breaker Type: BAB

• Number of Poles: 1

• Amperage Rating: 50 Amps

• Voltage Rating: 120/240V

• Interrupt Rating: 10 kAIC

• Trip Type: Non-Interchangeable

• Mounting Method: Bolt-On

• Dimensions:
  • Depth: 3.8 in.
  • Height: 4.8 in.
  • Width: 1.2 in.
• Product Weight: 0.35 lb

• Warranty: 1 Year


Material Compliance and Certifications

• UL Listed: Manufactured to meet UL listing requirements for electrical protection devices.
• CSA Certified: Certified to applicable CSA standards.
• HACR Rated: Suitable for HVAC and refrigeration applications.


Where It Works Best

• Commercial electrical panels
• HVAC and refrigeration systems
• Branch circuit protection
• Industrial control panels
• High intensity discharge lighting systems
• Electrical distribution systems
• Retrofit and maintenance applications
