BAB1030S - 30 Amp Circuit Breaker

BAB1030S - 30 Amp Circuit Breaker

The Eaton BAB1030S circuit breaker is a practical choice for commercial and industrial electrical systems that need reliable protection along with remote trip capability. Rated at 30 amps for 120/240V applications, this single-pole breaker helps protect your circuits from overloads and short circuits while adding the convenience of a built-in 120V shunt trip for remote shutdown applications.

Part of Eaton’s BAB Quicklag series, the BAB1030S uses thermal magnetic trip protection to react to both overload conditions and sudden fault currents. Its bolt-on mounting design provides a secure connection in compatible panelboards, and the compact size helps you make installation and replacement work easier. Since it’s HACR rated, it’s also commonly used in HVAC and refrigeration systems where dependable circuit protection is important every day.

Key Features and Benefits

• 30 amp thermal magnetic circuit breaker: Provides dependable circuit protection for commercial and industrial electrical systems.
• Single-pole design: Designed for standard single-pole electrical applications.
• 120/240V voltage rating: Suitable for low-voltage electrical systems.
• 10 kAIC interrupt rating: Helps protect against overloads and short circuits.
• Built-in 120V shunt trip: Supports remote shutdown applications.
• Eaton BAB Quicklag breaker: Built as part of Eaton’s BAB Quicklag series.
• Bolt-on mounting connection: Provides a secure connection in compatible panelboards.
• Thermal magnetic trip protection: Reacts to both overload conditions and sudden fault currents.


Technical Specifications

• Manufacturer: Eaton

• Catalog Number: BAB1030S

• Product Type: Thermal Magnetic Circuit Breaker

• Breaker Type: BAB

• Number of Poles: 1

• Amperage Rating: 30 Amps

• Voltage Rating: 120/240V

• Interrupt Rating: 10 kAIC

• Trip Type: Non-Interchangeable

• Shunt Trip: 120V

• Mounting Method: Bolt-On

• Dimensions:
  • Depth: 3.9 in.
  • Height: 4.8 in.
  • Width: 2.2 in.
• Product Weight: 0.6 lb

• Warranty: 1 Year


Material Compliance and Certifications

• UL Listed: Manufactured to meet UL listing requirements for electrical protection devices.
• CSA Certified: Certified to applicable CSA standards.
• HACR Rated: Suitable for HVAC and refrigeration systems.


Where It Works Best

• Commercial electrical panels
• HVAC and refrigeration systems
• Emergency shutdown systems
• Industrial control panels
• Branch circuit protection
• Electrical distribution systems
• Retrofit and maintenance applications
