BAB1030 - 30 Amp Circuit Breaker

BAB1030 - 30 Amp Circuit Breaker

The Eaton BAB1030 circuit breaker is designed for commercial and industrial electrical systems that need dependable circuit protection. Rated at 30 amps for 120/240V applications, this single-pole breaker helps protect your wiring and equipment from overloads and short circuits.

Part of Eaton’s BAB Quicklag series, the BAB1030 features thermal magnetic trip protection and a compact design that fits compatible panelboards with ease. It is also HACR rated, making it suitable for HVAC and refrigeration systems.

The BAB1030 is commonly used in commercial panels, lighting systems, industrial controls, and general electrical distribution applications.

Key Features and Benefits

• 30 amp thermal magnetic circuit breaker: Provides dependable circuit protection for commercial and industrial electrical systems.
• Single-pole design: Designed for standard single-pole electrical applications.
• 120/240V voltage rating: Suitable for low-voltage electrical systems.
• 10 kAIC interrupt rating: Helps protect against overloads and short circuits.
• Eaton BAB Quicklag breaker: Built as part of Eaton’s BAB Quicklag series.
• Thermal magnetic trip protection: Responds to both overload conditions and fault currents.
• HACR rated: Suitable for HVAC and refrigeration systems.
• Compact design: Fits compatible panelboards with ease.
• Helps protect against overloads and short circuits: Supports dependable operation in commercial and industrial applications.


Technical Specifications

• Manufacturer: Eaton

• Catalog Number: BAB1030

• Product Type: Thermal Magnetic Circuit Breaker

• Breaker Type: BAB

• Number of Poles: 1

• Amperage Rating: 30 Amps

• Voltage Rating: 120/240V

• Interrupt Rating: 10 kAIC

• Trip Type: Non-Interchangeable

• Dimensions:
  • Depth: 2.9 in.
  • Height: 2.9 in.
  • Width: 0.8 in.
• Product Weight: 0.3 lb

• Warranty: 1 Year


Material Compliance and Certifications

• UL Listed: Manufactured to meet UL listing requirements for electrical protection devices.
• CSA Certified: Certified to applicable CSA standards.
• HACR Rated: Suitable for HVAC and refrigeration applications.


Where It Works Best

• Commercial electrical panels
• HVAC and refrigeration systems
• Branch circuit protection
• Industrial control panels
• Lighting applications
• Electrical distribution systems
• Retrofit and maintenance applications
