BAB1025 - 25 Amp Circuit Breaker

BAB1025 - 25 Amp Circuit Breaker

The Eaton BAB1025 circuit breaker is a solid choice for commercial and industrial electrical systems that need dependable everyday protection. Rated at 25 amps for 120/240V applications, this single-pole breaker helps protect your circuits from overloads and short circuits before they turn into larger electrical problems or equipment damage.

As part of Eaton’s BAB Quicklag series, the BAB1025 uses thermal magnetic trip protection to respond to both overload conditions and sudden fault currents. Its compact size helps make installation easier in compatible panelboards, and the HACR rating makes it a common fit for HVAC and refrigeration systems as well. From branch circuit protection to lighting and control panel applications, this breaker is built for reliable performance in busy electrical environments.

The Eaton BAB1025 is often used in commercial buildings, industrial facilities, maintenance upgrades, and replacement projects where consistent circuit protection is important.

Key Features and Benefits

• 25 amp thermal magnetic circuit breaker: Provides dependable circuit protection for commercial and industrial electrical systems.
• Single-pole design: Designed for standard single-pole electrical applications.
• 120/240V voltage rating: Suitable for low-voltage electrical distribution systems.
• 10 kAIC interrupt rating: Helps protect against overloads and short circuits.
• Eaton BAB Quicklag breaker: Built as part of Eaton’s BAB Quicklag series.
• Thermal magnetic trip protection: Responds to both overload conditions and sudden fault currents.
• HACR rated for HVAC applications: Suitable for HVAC and refrigeration systems.
• Compact design for easier installation: Helps simplify installation and replacement work in compatible panelboards.
• Helps protect against overloads and short circuits: Supports reliable operation in commercial and industrial electrical environments.


Technical Specifications

• Manufacturer: Eaton

• Catalog Number: BAB1025

• Product Type: Thermal Magnetic Circuit Breaker

• Breaker Type: BAB

• Number of Poles: 1

• Amperage Rating: 25 Amps

• Voltage Rating: 120/240V

• Interrupt Rating: 10 kAIC

• Trip Type: Non-Interchangeable

• Dimensions:
  • Depth: 4 in.
  • Height: 5 in.
  • Width: 1 in.
• Product Weight: 0.35 lb

• Warranty: 1 Year


Material Compliance and Certifications

• UL Listed: Manufactured to meet UL listing requirements for electrical protection devices.
• CSA Certified: Certified to applicable CSA standards.
• HACR Rated: Suitable for heating, air conditioning, and refrigeration applications.


Where It Works Best

• Commercial electrical panels
• HVAC and refrigeration systems
• Branch circuit protection
• Industrial control panels
• Lighting applications
• Electrical distribution systems
• Retrofit and maintenance projects
• General commercial electrical applications
