B380HH00S01 - 80Amp Circuit Breaker

B380HH00S01 - 80Amp Circuit Breaker

The Siemens B380HH00S01 circuit breaker is designed for commercial and industrial electrical systems that require dependable circuit protection and remote trip capability. Rated at 80 amps with a 3-pole configuration, this Type BL molded case circuit breaker helps protect your equipment and distribution systems from overloads and short circuits in 120/240VAC applications. Its built-in 120V shunt trip allows the breaker to be tripped remotely, making it useful for emergency shutoff systems and control applications where quick disconnect capability is important.

With a 65 kAIC interrupt rating, the B380HH00S01 is suitable for higher fault-current environments often found in industrial facilities, commercial buildings, and equipment panels.

Key Features and Benefits

• 80 Amp molded case circuit breaker: Built for dependable protection in commercial and industrial electrical systems.
• 3-pole design for 120/240VAC applications: Designed for three-phase electrical distribution systems.
• Thermal magnetic trip protection: Responds to overload conditions and fault currents.
• 65 kAIC interrupt rating: Suitable for higher fault-current applications.
• Integrated 120V shunt trip for remote tripping: Supports emergency shutdown and control applications.
• Bolt-on mounting configuration: Provides a secure connection in compatible panelboards.
• Siemens Type BL construction: Built for dependable electrical distribution performance.
• UL 489 listed: Manufactured to meet low-voltage electrical distribution standards.


Technical Specifications

• Manufacturer: Siemens

• Catalog Number: B380HH00S01

• Breaker Type: Type BL

• Amperage Rating: 80A

• Voltage Rating: 120/240VAC

• Poles: 3-Pole

• Interrupt Rating: 65 kAIC

• Trip Type: Thermal Magnetic

• Special Feature: 120V Shunt Trip

• Connection Type: Bolt-On

• Application: Electrical Distribution

• Dimensions:
  • Depth: Approx. 6 in.
  • Width: Approx. 4 in.
  • Height: Approx. 4 in.
• Weight: Approx. 1.565 lbs.


Material Compliance and Certifications

• UL 489 Standards: The Siemens B380HH00S01 meets UL 489 standards for molded case circuit breakers and is intended for use in commercial and industrial electrical distribution systems requiring reliable overcurrent protection.


Where It Works Best

• This breaker works well in commercial panelboards, industrial distribution equipment, OEM machinery, and facilities that require remote trip functionality as part of a safety or control system.
