B370HH00S01 - 70Amp Circuit Breaker

B370HH00S01 - 70Amp Circuit Breaker

The Siemens B370HH00S01 circuit breaker is built for commercial and industrial electrical systems that need dependable protection and remote trip capability. Rated at 70 amps with a 120/240VAC rating, this 3-pole molded case circuit breaker helps protect your equipment and power distribution systems from overloads and short circuits before they become larger problems.

A factory-installed 120V shunt trip allows the breaker to trip remotely through connected safety or emergency shutdown systems, making it a practical option for facilities where quick disconnect capability is important. The thermal magnetic trip mechanism responds to both overloads and fault currents to help maintain safe and reliable operation.

Key Features and Benefits

• 70 amp molded case circuit breaker: Built for commercial and industrial electrical applications.
• 3-pole configuration for three-phase systems: Designed for dependable three-phase power distribution.
• Factory-installed 120V shunt trip: Allows remote tripping through connected safety or emergency shutdown systems.
• 120/240VAC voltage rating: Suitable for low-voltage electrical distribution systems.
• 65kA interrupting capacity: Designed for applications requiring higher fault-current protection.
• Thermal magnetic trip protection: Responds to overloads and fault currents to help maintain safe operation.
• Bolt-on mounting design: Provides a secure fit in compatible panelboards and distribution equipment.
• Compact Siemens HBL construction: Helps conserve panel space in commercial and industrial installations.
• Designed for commercial and industrial electrical systems: Suitable for a wide range of electrical distribution applications.
• UL 489 listed: Built to meet recognized low-voltage electrical protection standards.


Technical Specifications

• Manufacturer: Siemens

• Catalog Number: B370HH00S01

• Product Type: Molded Case Circuit Breaker

• Series: HBL

• Amperage Rating: 70 Amps

• Number of Poles: 3

• Voltage Rating: 120/240VAC

• Interrupt Rating: 65kAIC

• Trip Type: Thermal Magnetic

• Special Feature: 120V Shunt Trip

• Mounting Type: Bolt-On

• Application: Electrical Distribution

• Standard: UL 489

• Dimensions:
  • Depth: 6 in.
  • Height: 4 in.
  • Width: 4 in.
• Net Weight: 1.585 lb

• Country of Origin: Mexico


Material Compliance and Certifications

• UL 489 Standards: The Siemens B370HH00S01 circuit breaker is manufactured to meet UL 489 standards for low-voltage electrical distribution applications.


Where It Works Best

• Commercial buildings
• Industrial facilities
• Manufacturing equipment
• HVAC systems
• Motor control centers
• Emergency shutdown systems
• Panelboards and switchboards
• Three-phase electrical systems
• Electrical distribution equipment
• Replacement and retrofit projects
