A230 - 30 Amp Circuit Breaker

A230 - 30 Amp Circuit Breaker

If you’ve ever opened a packed electrical panel and wondered where another breaker could possibly fit, the A230 was made for situations like that. This 2-pole, 30-amp space-saver circuit breaker is designed to provide reliable circuit protection while freeing up valuable panel space. Its compact plug-in design makes it a solid choice for replacements, upgrades, or routine electrical service work where space is already at a premium.

Built for 120/240 VAC applications, the A230 helps protect electrical systems from overloads and short circuits before they escalate into bigger problems. The outside power stab configuration allows for proper compatibility in designated panels, and the slim profile helps make installations a little less frustrating when working in tighter load centers. With a 10k A.I.C. rating, this breaker is designed to respond safely during fault conditions while supporting consistent electrical performance day after day.

Electricians often use breakers like the A230 for equipment that needs dependable 30 amp protection, including water heaters, dryers, HVAC systems, and subpanels. It’s a practical, no-nonsense solution that gets the job done without taking up more room than necessary.

Key Features and Benefits

• Space-saver design: Helps maximize panel capacity.
• 30 amp, 2-pole breaker: Designed for 120/240VAC systems.
• Plug-in mounting style: Supports convenient installation.
• 10k A.I.C. rating: Provides reliable fault interruption.
• Circuit protection: Helps protect circuits from overloads and short circuits.


Technical Specifications

• Part Number: A230

• Poles: 2

• Amperage: 30A

• Voltage Rating: 120/240VAC

• A.I.C. Rating: 10k @ 120/240VAC

• Frame Type: A

• Mounting Type: Plug-In

• Breaker Type: Space-Saver

• Dimensions:
  • Width: 1.00"
  • Height: 3.38"
  • Depth: 2.63"
• Additional Notes: Power stabs on the outside


Material Compliance and Certifications

• The A230 circuit breaker is manufactured for use in compatible electrical distribution systems and is intended to support safe overcurrent protection in residential and commercial applications. Installation should always follow applicable electrical codes and be completed by a qualified professional.


Where It Works Best

• The A230 is commonly used in homes, apartment buildings, retail spaces, workshops, and light commercial properties where saving panel space matters. It’s especially useful for dedicated 240V circuits powering HVAC equipment, electric dryers, water heaters, and similar applications requiring a 30 amp double-pole breaker.
