A130R - 30 Amp Circuit Breaker

A130R - 30 Amp Circuit Breaker

The A130R 30 Amp circuit breaker is a good fit for protecting residential and light commercial electrical systems without taking up extra space in the panel. Its thin design helps free up valuable space, which can make a real difference when working inside crowded load centers or older electrical panels.

Built with thermal magnetic protection, the A130R helps guard circuits against overloads and short circuits before they can cause damage to wiring or connected equipment. The plug-in style keeps installation simple, and the molded case construction is made for dependable day-to-day use. It also includes a “power hook" on the rejection side for proper fit in compatible panel setups.

This breaker is often used for lighting circuits, HVAC equipment, appliance connections, and general branch circuit protection. Whether you’re replacing an existing breaker or handling routine electrical maintenance, the A130R offers a straightforward solution that’s compact, reliable, and easy to work with.

Key Features and Benefits

• 30 Amp Single-Pole Circuit Breaker: Designed for protecting residential and light commercial branch circuits.
• Thin Design: Helps save valuable panel space, especially in crowded load centers and older electrical panels.
• Plug-In Style: Allows for convenient installation in compatible electrical panels.
• Thermal Magnetic Protection: Helps guard against overloads and short circuits before damage can occur to wiring or connected equipment.
• Molded Case Construction: Built for dependable day-to-day performance and consistent electrical protection.
• “Power Hook” Compatibility: Includes a “power hook” on the rejection side for proper fit in compatible panel setups.
• Compact Size: Works well in tight panel layouts, replacement jobs, and retrofit applications.
• 10k A.I.C. Rating: Rated 10k A.I.C. at 120VAC for reliable circuit interruption.


Technical Specifications

• Part Number: A130R

• Type: A

• Poles: 1

• Amperes: 30A

• Voltage Rating: 120VAC

• A.I.C. Rating: 10kA @ 120VAC

• Breaker Style: Thin Type, Plug-In

• Trip Unit: Thermal Magnetic

• Construction: Molded Case Circuit Breaker

• Dimensions:
  • Width: 0.50"
  • Height: 3.38"
  • Depth: 2.63"

Material Compliance and Certifications

• Electrical Distribution Compatibility: The A130R circuit breaker is manufactured for use in electrical distribution systems that require reliable circuit protection.
• Installation Requirements: Installation should always follow local electrical codes and manufacturer recommendations.


Where It Works Best

• Residential breaker panels
• Apartment and condo electrical systems
• Office and retail spaces
• HVAC and appliance circuits
• Lighting and branch circuit protection
• Panel upgrades and replacement projects
• Tight load centers with limited space
