997217 - 125 Amp Circuit Breaker

997217 Molded Case Circuit Breaker – 125 Amp, 2 Pole, 600VAC, ML Frame

If you're replacing a breaker in an existing setup, you already know the job isn’t about experimenting—it’s about getting the right match. The 997217 molded case circuit breaker is built to fit into compatible systems without forcing changes. It carries a 125 amp rating, uses a 2-pole configuration, and is designed for up to 600VAC applications commonly found in commercial and industrial environments. This unit features a thermal-magnetic trip, so it reacts to both long-term overloads and sudden short circuits. That’s the kind of protection most legacy systems were originally designed around. Built on an ML (J-Frame) platform, it’s intended to line up with existing equipment where form and fit matter just as much as the electrical rating. It’s straightforward, does what it’s supposed to do, and holds up over time.

Key Features and Benefits

• 125 amp capacity suited for a wide range of applications
• 2-pole configuration for proper circuit coverage
• Thermal-magnetic trip responds to both overload and fault conditions
• Rated for 600VAC systems
• ML (J-Frame) design for compatibility with existing equipment
• Molded case construction built for long-term use

Technical Specifications

• Part Number: 997217
• Amperage: 125A
• Poles: 2
• Voltage Rating: 600VAC
• Frame Type: ML (J-Frame)
• Trip Type: Thermal-Magnetic
• Dimensions: 6.00"W x 10.38"L x 3.88"D
• Weight: 15 lbs

Material Compliance and Certifications

• Built to meet commonly accepted industry standards for molded case circuit breakers
• Suitable for installations following National Electrical Code (NEC) guidelines
• Uses standard materials typical for electrical distribution components

Where It Works Best

• Existing commercial and industrial panel systems
• 600VAC electrical distribution setups
• Maintenance and repair applications
• Situations where matching ML / J-Frame breakers is required
• Facilities keeping older systems in service
