If you’re maintaining an existing motor control system, the Square D 9065TR5.5 thermal overload relay is the kind of component that helps keep equipment operating the way it should. Designed for 3-phase applications, this Class 9065 relay provides adjustable overload protection from 5.5A to 8.3A and is commonly used in motor starters, control panels, and industrial equipment where reliable protection is needed to help prevent motor overheating.

The open-style design keeps installation simple inside compatible assemblies, while the compact footprint works well in tighter panel layouts. This relay is frequently found in manufacturing facilities, HVAC systems, pump controls, and conveyor equipment where older Square D motor control components are still in service. For maintenance teams and electricians, having the correct overload relay matters — especially when matching existing equipment specifications and keeping downtime to a minimum. Like many Square D control components from this series, the 9065TR5.5 was built for long-term use in demanding industrial environments.

Key Features and Benefits

• Adjustable Overload Protection: Adjustable overload setting from 5.5A to 8.3A.
• Three-Phase Motor Compatibility: Designed for 3-phase motor control systems.
• Motor Overload Protection: Helps protect motors from overload conditions.
• Open-Style Configuration: Open-style configuration for compatible starter assemblies.
• Compact Panel Fit: Compact size fits many existing panel layouts.
• Industrial and Commercial Use: Commonly used in industrial and commercial equipment.
• Square D System Replacement: Suitable for replacement in existing Square D systems.
• Dependable Daily Operation: Built for dependable day-to-day operation.


Technical Specifications

• Manufacturer: Square D

• Part Number: 9065TR5.5

• Class: 9065

• Type: TR 5.5

• Product Type: Thermal Overload Relay

• Phase: 3 Phase

• Poles: 3

• Ampere Range: 5.5A – 8.3A

• Enclosure Type: Open

• Dimensions:
  • Height: 2.75 in.
  • Width: 1.75 in.
  • Depth: 3.06 in.

Material Compliance and Certifications

• Industrial Motor Control Applications: The Square D 9065TR5.5 thermal overload relay is manufactured for industrial motor control applications and is designed for use in systems requiring components from the Square D Class 9065 product family.
• Installation Verification: Always verify compatibility with the intended equipment and local electrical requirements before installation.


Where It Works Best

• The 9065TR5.5 is commonly used in industrial motor starters, manufacturing equipment, conveyor systems, pump and fan controls, HVAC applications, OEM machinery, commercial control panels, and existing Square D motor control systems.
