Siemens

3VA4150-5ED24-0AA0 - 50Amp Circuit Breaker

3VA4150-5ED24-0AA0 - 50Amp Circuit Breaker

Regular price $0.00 USD
Regular price Sale price $0.00 USD
Sale Sold out
Shipping calculated at checkout.
Condition

3VA4150-5ED24-0AA0 åÊ- åÊ50Amp Circuit Breaker

The Siemens 3VA4150-5ED24-0AA0 circuit breaker is a high-performance, molded case circuit breaker that offers reliable protection for electrical systems in both commercial and industrial applications. With a robust 35 kA breaking capacity at 480V, this breaker is designed to safeguard circuits against high fault currents. The breaker features a TM210 thermal-magnetic trip unit, providing essential overload and short-circuit protection for sensitive equipment. The fixed short-circuit protection setting (Ir=50 A) ensures ongoing, dependable operation, making this circuit breaker an ideal choice for a wide range of electrical systems requiring reliable and high-capacity protection.

Key Features and Benefits

  • Thermal-Magnetic Protection (TM210): The thermal-magnetic trip unit ensures that the breaker provides both overload and short-circuit protection, reducing the risk of damage to electrical circuits and connected equipment.
  • Fixed Short-Circuit Protection (Ir): This circuit breaker is equipped with fixed short-circuit protection (Ir=50 A), providing reliable and continuous safety for the electrical system.
  • Class M Protection: Class M protection is built into the breaker, ensuring that it operates at high levels of performance and can handle substantial fault conditions.
  • Terminal Connection: Featuring easy-to-use terminal connections, this circuit breaker is designed for quick installation, providing efficiency in both commercial and industrial settings.

Technical Specifications

  • Frame Size: 125
  • Rated Current (In): 50 A
  • Rated Short-Circuit Protection (Ir): 50 A
  • Rated Breaking Capacity: 35 kA at 480V
  • Number of Poles: 2-pole
  • Short-Circuit Protection Setting (Ii): 10x In
  • Trip Unit Type: TM210 (Thermal Magnetic)
  • Weight: 0.514 kg
  • Dimensions (W x H x D): 135 x 168 x 58 mm

Material Compliance and Certifications

  • RoHS Compliant: The Siemens 3VA4150-5ED24-0AA0 complies with RoHS standards, ensuring that the product meets strict environmental and material safety guidelines.
  • UL Listed: Certified by UL, this circuit breaker meets North American safety standards, providing reassurance of its reliability and performance.
  • IEC Standards Compliant: The breaker also complies with international IEC standards, making it suitable for global applications.

Suitability

  • The Siemens 3VA4150-5ED24-0AA0 circuit breaker is ideal for applications that require reliable, high-capacity protection, including electrical panels, industrial machinery, and commercial electrical systems.åÊWith its high breaking capacity, advanced protection features, and UL certification, this circuit breaker offers dependable safety for a wide range of electrical installations, ensuring both operational efficiency and equipment protection.

Choose the Siemens 3VA4150-5ED24-0AA0 for superior circuit protection and long-term system reliability.
