3VA4111-6ED54-0AA0 - 110Amp Circuit Breaker

3VA4111-6ED54-0AA0 - 110Amp Circuit Breaker

The Siemens 3VA4111-6ED54-0AA0 is built for electricians and facility managers who need dependable circuit protection without extra hassle. This 110-amp breaker, part of the Siemens 3VA41 line, offers a strong 65kA interrupting capacity at 277 VAC — exactly what you want when higher fault currents are a concern. Its TM210 thermal-magnetic trip unit has fixed long-time and instantaneous settings, so it trips when it should and stays out of the way when it’s not needed. Designed with a 1-pole configuration in a 2-pole body, it fits neatly into your panel while providing straightforward load-side lug connections.

Key Features and Benefits

• High Fault Protection: Handles up to 65kA at 277 VAC, giving extra confidence in demanding applications.
• Consistent Operation: Fixed thermal and magnetic trip settings ensure the breaker reacts the same way every time.
• Simple Fit: 1-pole breaker packaged in a 2-pole body makes panel layouts easier.
• Quick Installation: Load-side lugs are ready to go right out of the box.
• Trusted Brand: Siemens breakers are known for lasting performance and quality engineering.

Technical Specifications

• Manufacturer: Siemens
• Part Number: 3VA4111-6ED54-0AA0
• Frame Type: 3VA41
• Trip Unit: TM210 Thermal-Magnetic (Fixed Long-Time / Fixed Instantaneous)
• Amperage: 110A
• Poles: 1 (in a 2-pole body)
• Interrupting Capacity: 65kA @ 277 VAC
• Dimensions:
  • Height: 5.1”
• Weight: 2.0 lbs
• Lug Location: Load-side only

Material Compliance and Certifications

• UL Listed: This breaker is UL Listed, meeting safety and performance requirements for molded case circuit breakers.
• Industry Compliance: Uses materials that comply with industry standards for low-voltage systems, helping you stay code-compliant on any project.

Where It Works Best

• Ideal for commercial buildings, manufacturing spaces, and other facilities that need reliable overcurrent protection. Great for use in panelboards, switchboards, and OEM assemblies where high fault protection is important.
