3VA4110-5ED24-0AA0 - 100Amp Circuit Breaker

3VA4110-5ED24-0AA0  -  100Amp Circuit Breaker

Protect your electrical systems with the Siemens 3VA4110-5ED24-0AA0. This 2-pole, 100-amp breaker is built for low-voltage applications and keeps your equipment safe from overloads and short circuits. With a 35kA interrupting rating at 480V and a TM210 thermal-magnetic trip unit, it reacts quickly when there’s a problem, helping prevent downtime. It’s compact and light—just 5.1 inches tall and 2 pounds—so it fits neatly into most panels.

Key Features and Benefits

• Reliable Protection: Keeps circuits safe from overloads and short circuits.
• Quick Response: TM210 trip unit reacts promptly to electrical faults.
• High Interrupting Capacity: Handles 35kA at 480V without issues.
• Compact & Easy to Install: Small size and light weight make it simple to work with.
• Simple Wiring: Lugs are installed on the load side only.

Technical Specifications

• Poles: 2
• Amperage: 100A
• Interrupting Rating: 35kA @ 480VAC
• Trip Unit: TM210, Fixed Ir / Fixed Ii
• Dimensions: Height 5.1 inches; Weight 2 pounds

Material Compliance and Certifications

• UL Listed for safety
• Siemens Low Voltage, Type 3VA molded case design
• MEAB (Class M) breaking capacity

Where It Works Best:

• Great for commercial buildings, industrial plants, and low-voltage panels. Its quick fault response and high interrupting rating make it a solid choice for keeping your systems running smoothly.
