3VA4110-5ED14-0AA0 - 100Amp Circuit Breaker

3VA4110-5ED14-0AA0 åÊ- åÊ100Amp Circuit Breaker

The Siemens 3VA4110-5ED14-0AA0 is a high-performance, single-pole molded case circuit breaker designed to provide superior protection for electrical systems. Featuring a UL Frame 125 and a powerful breaking capacity of 35 kA at 277 V, this circuit breaker ensures that your electrical installations are safeguarded against overloads and short circuits. The 3VA4110-5ED14-0AA0 is equipped with advanced overload protection (In=100 A) and short-circuit protection (Ir=100 A), as well as a tripping factor (Ii) of 10x In, offering optimal protection for sensitive equipment and circuits.

Key Features and Benefits

• Overload and Short-Circuit Protection: Includes overload protection (In=100 A) and short-circuit protection (Ir=100 A), with an instantaneous tripping factor (Ii) of 10x In for enhanced safety.
• Advanced Protection Technology: Incorporates TM210 and FTFM technologies for superior line protection, reducing the risk of system damage and ensuring operational continuity.
• Terminal Connection: Designed for easy integration and installation, this circuit breaker features a terminal connection for a seamless setup.

Technical Specifications

• Frame Size: UL Frame 125

• Breaking Capacity: 35 kA at 277 V

• Poles: 1-pole configuration, suitable for single-phase applications.

• Overload Protection: 100 A, permanently set

• Short-Circuit Protection: 100 A (Ir=100 A)

• Tripping Factor (Ii): 10 x In with terminal connection
• Weight: 0.280 kg

• Dimensions (Packaging): 135 mm x 168 mm x 34 mm


Material Compliance and Certifications

• RoHS Compliance: Fully compliant with RoHS regulations since January 1, 2017, ensuring environmentally responsible material use.
• Export Control Regulations: ECCN: EAR99, AL: N
• Certifications: UL Listed, ensuring it meets rigorous safety and performance standards.

Suitability

• The Siemens 3VA4110-5ED14-0AA0 is ideal for applications where reliable and efficient single-phase circuit protection is necessary.åÊIt is particularly suitable for use in residential, commercial, and light industrial environments, where robust protection against overloads and short circuits is essential.åÊThe compact design and advanced protection features make this breaker an excellent choice for professionals looking for a cost-effective, high-quality solution that doesn‰۪t compromise on performance.
